PSET PNEUMATIC WORKSTATION

Greater manual freedom and speed of execution compared to other clamping systems.
PSET positioning systems use a pneumatic clamping and unclamping system to quickly orient the workpiece to find the most suitable position.
Available in three sizes to cover many fields of application: P3X, P6S e P10S.

P10S

Accessories

<p>PED502M FOOT CONTROL VALVE</p><p>Bistable 5/2 pneumatic foot valve complete with fittings</p>

PED502M FOOT CONTROL VALVE

Bistable 5/2 pneumatic foot valve complete with fittings

<p>DMX43 RUBBERIZED FLAT PERMANENT MAGNETS</p><p>Permanent magnets with high magnetic force and protective rubber coating to hold metal parts without damaging them. Diam. 43 mm with M6 threaded stem.</p>

DMX43 RUBBERIZED FLAT PERMANENT MAGNETS

Permanent magnets with high magnetic force and protective rubber coating to hold metal parts without damaging them. Diam. 43 mm with M6 threaded stem.

<p>PMX300 - MAGNETIC PLATFORM</p><p>High magnetic power platform for holding even heavy ferromagnetic parts. The force of the magnet can be deactivated using an ON-OFF lever.</p>

PMX300 - MAGNETIC PLATFORM

High magnetic power platform for holding even heavy ferromagnetic parts. The force of the magnet can be deactivated using an ON-OFF lever.

<p>VACM-C  MULTI-CLAMP VACUUM PLATFORM</p><p>Vacuum clamping plate for holding objects with flat surfaces by means of the vacuum force generated by a Venturi system.</p>

VACM-C  MULTI-CLAMP VACUUM PLATFORM

Vacuum clamping plate for holding objects with flat surfaces by means of the vacuum force generated by a Venturi system.

Application fields

Painting, grinding, sanding, assembling, welding, finishing and manual processing.

specifications

  • Working pressure from 4 to 9 Bar Max.
  • External cover in painted sheet.
  • Base plate in anodized aluminum.
  • AISI 304 stainless steel platform complete with slots for anchoring clamps.
  • Support platform size: 400 x 310 mm
  • Reach 25 kg
  • Still life of the P10S product on a grey background
  • Still life of the positioner with foot pedal
Technical sheet
Use and maintenance manual
Accessories Catalogue
post-sales supportquotations

P6S

Accessories

<p>PED502M FOOT CONTROL VALVE</p><p>Bistable 5/2 pneumatic foot valve complete with fittings</p>

PED502M FOOT CONTROL VALVE

Bistable 5/2 pneumatic foot valve complete with fittings

<p>DMX43 RUBBERIZED FLAT PERMANENT MAGNETS</p><p>Permanent magnets with high magnetic force and protective rubber coating to hold metal parts without damaging them. Diam. 43 mm with M6 threaded stem.</p>

DMX43 RUBBERIZED FLAT PERMANENT MAGNETS

Permanent magnets with high magnetic force and protective rubber coating to hold metal parts without damaging them. Diam. 43 mm with M6 threaded stem.

<p>VACM-C  MULTI-CLAMP VACUUM PLATFORM</p><p>Vacuum clamping plate for holding objects with flat surfaces by means of the vacuum force generated by a Venturi system.</p>

VACM-C  MULTI-CLAMP VACUUM PLATFORM

Vacuum clamping plate for holding objects with flat surfaces by means of the vacuum force generated by a Venturi system.

Application fields

Painting, grinding, sanding, welding, finishing, manual processing on medium-sized objects.

specifications

  • Working pressure from 4 to 9 Bar Max.
  • Painted sheet metal outer cover.
  • Anodised aluminium base plate.
  • Equipped platform in AISI 304 complete with slots for anchoring clamps.
  • Support platform size: 240 x 180 mm
  • Load capacity 10 kg
  • Still life of P6S product on grey background
  • Still life of the positioner with foot pedal
Technical data sheet
Use and maintenance manual
Accessories Catalogue
post-sales supportquotations

P3X

Accessories

<p>PED502M FOOT CONTROL VALVE</p><p>Bistable 5/2 pneumatic foot valve complete with fittings</p>

PED502M FOOT CONTROL VALVE

Bistable 5/2 pneumatic foot valve complete with fittings

<p>Manual valve 5-2 bistable complete with fittings</p>

Manual valve 5-2 bistable complete with fittings

Application fields

Painting, sanding, tin welding, finishing and small manual processing on small objects.

specifications

  • Working pressure from 4 to 9 Bar Max.
  • External cover in mirror-polished AISI 304.
  • Black anodised aluminium base plate.
  • AISI 304 platform supplied complete with slots for anchoring clamps.
  • Support platform size: 120 x 90 mm
  • Capacity 800 g
  • Still life of the P3X product on a grey background
  • Still life of the positioner with foot pedal
Technical data sheet
Use and maintenance manual
Accessories Catalogue
post-sales supportquotations

PMI-10S

Application fields

Luthiers, electronics, woodwork, assembling

specifications

  • Working pressure from 4 to 9 Bar Max.
  • Complete platform with slots and 4 repositionable suction cups.
  • Platform size: 350 x 320 mm
  • Load capacity 10 kg
  • Working platform with P10S positioner
  • Platform for musical instruments with P10S positioner
  • Platform with guitar
  • Platform with guitar
post-sales supportquotations

resellers

Deutschland

WSN Werkzeugsysteme-Nord GbR

street:

Karl-Lilienthal-Strasse 6 - Lilienthal

zip:

28865

Tel:

+49 04298-9215678 - +491743136403

Web:

www.werkzeugsysteme-nord.de

Espania

Seyber Representaciones, S.L.

street:

C. Moralzarzal, 14 - Alcorcón, Madrid

zip:

28925

Tel:

+34 916 32 71 53

Web:

www.seyber.com

Espania

INDUSTRIAS ENRIQUE GALAN, S.A.

street:

C/Fluvià n° 79 - Barcelona

zip:

08019

Tel:

+34 932 174808

Web:

www.iegalan.es

France

OTELO SA

street:

11 Av. du Fief, Saint-Ouen-l'Aumône

zip:

95310 (Parc d'activités des Béthunes)

Tel:

+33134303910

Web:

www.otelo.fr

Poland

MICHAŁ JARUGA

street:

Ul. Szarych Szeregów 42A - Poznań

zip:

60-642

Tel:

+48 602 413540

Web:

www.ustawnik.pl

Poland

WOLSEN Sp. z o.o.

street:

Potarzyca, ul. Gajowa 1 - Jarocin

zip:

63-200

Tel:

+48 62 33 22 880

Web:

www.wolsen.pl

Portugal

LTS – TECH

street:

Rua dos Chãos Velhos, N. 673 - Arcozelo -
Vila Nova de Gaia

zip:

4410-443

Tel:

+35 1 22 3299971

Web:

www.lts-tech.pt

Romania

METAL STAR SRL

street:

Traian Str. 43-45 AB, Alba Iulia

zip:

510109

Tel:

+40 258 819046

Web:

https://www.mstar.ro

PSET headquarters

street Giovanni Alberti, 42/B

27053 Lungavilla (PV)

Italy

phone:

+39 320 0325818

about us

Founded in 2018, PSET is an Italian factory lab which develops and produces Pneumatic Positioners in its own head quarters thanks to deep technical and mechanical experience and also innovation due to the direct contact with customers. These are innovative pneumatic devices that Position work pieces for wide use, dedicated to the sectors of specialized manual jobs. All our products are totally made in Italy with the highest level of quality. The application of our devices goes from Mechanical projects to Automation, from Carpentry to Leather accessories processing, from the Electrotechnical sector to Mechanical Assembly, from the Jewellery sector to Lutherie and more.

Frequently asked questions

How much weight can it carry?

For reasons of safety and working precision, the weight of the object to be anchored on the plates is:
for P3x 1Kg
for P6S 10Kg
for P10S 25Kg

To avoid losing the warranty, do not exceed the indicated weight.

Can it be used on machine tools?

Absolutely NOT. PSET devices are exclusively dedicated to manual machining.

What are the pressures of use?

Recommended pressures from 4 to 9 Bar max.

Can it work vertically?

Yes, it can be used in a vertical position.

What happens if there is no air?

The platform remains safely locked in the last working position.

Can it also be connected to the home compressor?

Yes, it can also be connected to the home compressor.

Can it be connected to the company compressed air network?

Yes, it can be connected to the company’s compressed air network.
